32 differential channels simultaneous sampling,
0.2 mcV RMS noise on shorted channels at 512 SPS,
4xAD7771BCPZ 64 kSPS,
STM32H743ZIT6 MCU 1027 DMIPS,
isolated USB, UART, SPI,
SD-Card,

FreeEEG32 + alpha1.5 32 channels 5min eyes closed, https://github.com/neuroidss/FreeEEG32-alpha1.5/blob/master/OpenVIBE/gdf...,

ciPLV 32 channel coherence onboard with Butterworth filtering, output via isolated USB, UART, SPI, and SD-Card https://github.com/neuroidss/FreeEEG32-alpha1.5/blob/master/AC6/STM32H74...,

for multi-architecture amd64, arm64, armhf docker containers with OpenVIBE https://github.com/neuroidss/FreeEEG32-alpha1.5/blob/master/multiarch/op...

gerber: https://github.com/neuroidss/FreeEEG32-alpha1.5/raw/master/KiCAD/out/ger...

bom: https://docs.google.com/spreadsheets/d/1l08JTSrGSRcxZXpl6SzznG30cp7E945A...

https://hackaday.io/project/166893-freeeeg32-alpha15

https://github.com/neuroidss/FreeEEG32-alpha1.5

, , , ,

Mobile transcranial altering current stimulator.
For implement results shown in paper about working memory increase with stimulation of 6 and 80 herz.

Spatial Working Memory in Humans Depends on Theta and High Gamma Synchronization in the Prefrontal Cortex
https://www.cell.com/current-biology/fulltext/S0960-9822%2816%2930358-X

Sources from quicksilv3rflash: https://github.com/neuroidss/FreetACS
Calculation of components: https://goo.gl/UaXZKf

,

Fast reading is achieved by increasing the text display speed up to the disappearance of the internal dialogue.

Electroencephalography read electromyogram of glossopharyngeal and hypoglossal nerve when pronouncing the words aloud and with inner voice.

Produced Fourier analysis of the difference of channels.
