32 differential channels simultaneous sampling,
0.2 mcV RMS noise on shorted channels at 512 SPS,
4xAD7771BCPZ 64 kSPS,
STM32H743ZIT6 MCU 1027 DMIPS,
isolated USB, UART, SPI,
SD-Card,

FreeEEG32 + alpha1.5 32 channels 5min eyes closed, https://github.com/neuroidss/FreeEEG32-alpha1.5/blob/master/OpenVIBE/gdf...,

ciPLV 32 channel coherence onboard with Butterworth filtering, output via isolated USB, UART, SPI, and SD-Card https://github.com/neuroidss/FreeEEG32-alpha1.5/blob/master/AC6/STM32H74...,

for multi-architecture amd64, arm64, armhf docker containers with OpenVIBE https://github.com/neuroidss/FreeEEG32-alpha1.5/blob/master/multiarch/op...

gerber: https://github.com/neuroidss/FreeEEG32-alpha1.5/raw/master/KiCAD/out/ger...

bom: https://docs.google.com/spreadsheets/d/1l08JTSrGSRcxZXpl6SzznG30cp7E945A...

https://hackaday.io/project/166893-freeeeg32-alpha15

https://github.com/neuroidss/FreeEEG32-alpha1.5

Mobile transcranial altering current stimulator.
For implement results shown in paper about working memory increase with stimulation of 6 and 80 herz.

Spatial Working Memory in Humans Depends on Theta and High Gamma Synchronization in the Prefrontal Cortex
https://www.cell.com/current-biology/fulltext/S0960-9822%2816%2930358-X

Sources from quicksilv3rflash: https://github.com/neuroidss/FreetACS
Calculation of components: https://goo.gl/UaXZKf

About us

Misson of NeuroIDSS: Radical increase of working memory for strategic autonomy

There is a cognitive bias leading to the lack of meaning, this is also due to the fact that we simplify numbers and probabilities to make it easier to think about them, and this also happens because there is a magical number 7+-2, which correlates with the size of working memory in the brain.
A 32-channel EEG brain-computer interface FreeEEG32 for measuring working memory has been designed and manufactured, and an alternating current stimulator FreetACS has been produced to increase working memory.

It is difficult to say whether there is much sense in increasing of working memory, but we can definitely say that without increasing of working memory, there is less sense.
